AT-TQ5403 and AT-TQm5403 Access Point User’s Guide
79
3. Select a VAP to configure from the next sub-menu. The default is
VAP0. You can configure only one VAP at a time.
4. Select the Security tab.
5. Select WPA Personal from the Mode pull-down menu. Refer to
Figure 22.
Figure 22. WPA Personal Security Tab
6. Configure the parameters by referring to Table 14.
Table 14. WPA Personal Security Tab
Field Description
Mode Select WPA Personal.
WPA Version Select the WPA version. The options are listed
here:
- WPA and WPA2: Select this option if the VAP
has both WPA and WPA2 clients.
- WPA2: Select this option if clients support
WPA2, but not WPA. This is the default setting.
