Chapter 3: Beginning the Installation
100
Figure 32 lists the items that are included in the accessory kit for thex530-
10GHXm and x530-18GHXm. Contact your Allied Telesis sales
representative for assistance if any item is missing or damaged.
Figure 32. Accessory Kit Items
Two or four wall/equipment rack
brackets depending on the model.
1417
One 2m (6.6 ft) local management
cable with RJ-45 (8P8C) and DB-9
(D-sub 9-pin) connectors.
Eight or sixteen screws for attaching
the wall/equipment rack brackets
depending on the model.
Length: 6.0mm (0.2 in.)
Diameter: 4.0mm (0.2 in.)
Two regional AC power cords.
1570
Two power cord retaining clips
1947
1570
1947
2047
2047
Four bumper feet with
rivets
