Chapter 6: Installing the Switch on a Wall
122
Installing the Switch on a Plywood Base
After the plywood base for the switch has been installed on the wall, install
the switch. See “Reviewing Safety Precautions” on page 92 and
“Choosing a Site for the Switch” on page 97 before performing this
procedure. Allied Telesis recommends a minimum of two people for this
procedure.
Warning
The device is heavy. Always ask for assistance before moving or
lifting it to avoid injuring yourself or damaging the equipment.
Warning
The device should be installed on the wall by a qualified building
contractor. Serious injury to yourself or others or damage to the
equipment can result if it is not properly fastened to the wall.
E105
To install the switch on the plywood base, perform the following
procedure:
1. Place the switch on a table.
2. For the x530-28GTXm or x530-28GSX switch, install two wall/
equipment rack brackets to the sides of the unit with the eight
M4x6mm screws included with the switch. Refer to Figure 46 on page
123. For the x530-10GHXm, x530-18GHXm, x530-28GPXm, x530-
52GPXm or x530-52GTXm switch, install four wall/equipment rack
brackets to the sides of the unit with the 16 M4x6mm screws included
with the switch. Refer to Figure 47 on page 124.
Note
The x530-10GHXm, x530-18GHXm, x530-28GPXm, x530-52GPXm
or x530-52GTXm switch requires four brackets to be installed due to
its weight. Whereas, the x530-28GTXm or x530-28GSX switch only
requires two brackets because it is lighter.
