x530 Series Installation Guide for Virtual Chassis Stacking
141
awplus>
The prompt identifies the User Exec mode of the command line
interface.
6. Go to “Verifying the Stack” on page 143.
Without a DHCP
or DHCPv6
Server
To start a management session on the switch over a network without a
DHCP or DHCPv6 server, perform the following procedure:
1. Change the IP address of your workstation to 169.254.42.n/16
(255.255.0.0), where n is any number from 1 to 254, but not 42.
2. Connect the Ethernet port on your workstation to an Ethernet port on
the switch.
3. Power on the switch. Wait several minutes for it to finish loading the
AlliedWare Plus software.
4. Enter the IP address 169.254.42.42, the switch’s default IP address, in
an SSH application or the URL field of the web browser on your
workstation.
5. Press Enter. You are prompted for the name and password of the
manager account.
6. Enter the user name and password. The default values are “manager”
and “friend” (without the quotes), respectively.
Note
User names and passwords are case sensitive.
The switch starts the local management session and displays the
following prompt:
awplus>
The prompt identifies the User Exec mode of the command line
interface.
7. Go to “Verifying the Stack” on page 143.
8. Configure the terminal or terminal emulator program as follows:
 Default baud rate: 9,600 bps (range is 9,600 to 115,200 bps)
 Data bits: 8
 Parity: None
 Stop bits: 1
