x530 Series Installation Guide for Virtual Chassis Stacking
63
Stack Trunks
Stack trunks connect the switches of a stack together. A stack trunk
consists of a minimum of two ports on each device. For switches with
AlliedWare Plus v5.5.1-1.2 or later, you can choose the ports of the trunk.
Your choices are listed in Table 19:
The guidelines are discussed in the following sections:
 “Stack Trunks of the Default 10Gbps SFP+ S1 and S2 Stacking Ports”
on page 64
 “Stack Trunks of 5Gbps Copper Ports” on page 69
 “Stack Trunks of 1Gbps Copper Ports” on page 72
 “Stack Trunks of 1Gbps SFP Ports 1 to 24 on x530-28GSX Switches”
on page 74
Note
The following discussions apply to AlliedWare Plus v5.5.1-1.2 or
later. Earlier versions of the operating system have different trunk
rules and restrictions.
Table 19. Trunk Ports
Switch
SFP+ S1 and
S2 Ports
(Default)
Additional
SFP+ Ports
Copper 5G
Multi-speed
Ports
Copper 1G
Ports
SFP 1G Ports
x530-10GHXm 9/S1, 10/S2 None 1-8
1
None None
x530-18GHXm 17/S1, 18/S2 None 1-16
1
None None
x530-28GPXm 27/S1, 28/S2 25, 26 21-24
2
1-20 None
x530-28GTXm 27/S1, 28/S2 25, 26 21-24
3
1-20 None
x530-28GSX 27/S1, 28/S2 25, 26 None None 1-24
x530-52GPXm 51/S1, 52/S2 49, 50 41-48
2
1-40 None
x530-52GTXm 51/S1, 52/S2 49, 50 41-48
3
1-40 None
1. PoE++ copper ports.
2. PoE+ copper ports.
3. Non-PoE+ copper ports.
