Chapter 1: Overview
46
The states of the x530-28GPXm LEDs are described in Table 14.
Table 14. x530-28GPXm Copper Ports 1 - 24 LED Functions
LED Ports State Description
L/A
1 - 20
Solid Green The port has established a 1Gbps link to a network
device.
Flashing
Green
The port is transmitting or receiving data at 1Gbps.
Solid Amber The port has established a 10Mbps or 100Mbps link
to a network device.
Flashing
Amber
The port is transmitting or receiving data at 10Mbps
or 100Mbps.
21 - 24
Solid Green The port has established a 1/2.5/5Gbps link to a
network device.
Flashing
Green
The port is transmitting or receiving data at
1/2.5/5Gbps.
Solid Amber The port has established a 100Mbps link to a
network device.
Flashing
Amber
The port is transmitting or receiving data at
100Mbps.
Off Possible causes of this state are:
- The port has not established a link with another
network device.
- The LEDs are turned off. To turn on the LEDs, use
the eco-friendly button.
