x530 Series Installation Guide for Virtual Chassis Stacking
29
Table 4. x530-18GHXm Switch Copper Port Specifications
Specification Description
Port Speed Ports 1 - 16: 100Mbps or 1/2.5/5Gbps.
100Mbps: Set the port speed manually or with
Auto-Negotiation.
1/2.5/5Gbps: The port speed is set with Auto-
Negotiation only.
The default is Auto-Negotiation for all ports.
Duplex Mode Ports 1 - 16:
100Mbps: Full- or half-duplex mode.
1/2.5/5Gbps: Full-duplex mode only.
Supports Auto-Negotiation at 100Mbps.
Maximum Distance 100 meters (328 feet)
Power over Ethernet
PoE (15.4W maximum per port) / 16 PDs
PoE+ (30W maximum per port) / 16 PDs
PoE++(60W maximum per port) / 16 PDs
PoE++(90W maximum per port) / 11 PDs
Maximum Power Budget 1,000W (500W per power supply)
PoE Mode Classes 0 to 8: Mode A and B (all eight
strands)
Connector 8-pin RJ-45
