Duplex Mode The copper ports can operate in either half- or full-duplex mode at 10Mbps
or 100Mbps and full-duplex only at higher speeds.
The duplex mode of a port operating at 10Mbps or 100Mbps, like port
speed, can be set manually using the management software or
automatically with Auto-Negotiation (IEEE 802.3u), the default setting.
The speed and duplex mode settings of a port can be set independently of
each other. For example in the case of a 10Mbps or 100Mbps port, it can
be configured such that its speed is set manually while its duplex mode is
established through Auto-Negotiation.
Table 8. x530-52GPXm Switch Copper Port Specifications
Specification Description
Port Speed Ports 1 - 40: 10Mbps/100Mbps/1000Mbps.
Ports 41 - 48: 100Mbps or 1/2.5/5Gbps
Ports 1 - 40: Set the port speed manually
or with Auto-Negotiation at 10Mbps, and
100Mbps.
Ports 41 - 48: The port speed is set with
Auto-Negotiation only, at 1Gbps and
higher.
The default is Auto-Negotiation for all
ports.
Duplex Mode Ports 1 - 40: Full- or half-duplex mode at
100Mbps. Full-duplex only at 1Gbps.
Supports Auto-Negotiation at 10Mbps and
100Mbps.
Ports 41- 48: Full-duplex only at all speeds.
Maximum Distance 100 meters (328 feet).
Power over Ethernet PoE (15.4W maximum per port) and PoE+
(30W maximum per port).
Maximum Power Budget 740W (370W per power supply).
PoE Mode Mode A.
Connector 8-pin RJ-45.
