Chapter 1: Overview
26
Management Panel
Figure 10 identifies the components on the management panel.
Figure 10. Management Panel
CLASS
1
LASER PRODUCT
CONSOLE
4567
Console
eco-friendly
Button
USB
Port
Switch
ID LED
Management
Port
