Chapter 1: Overview
44
The states of the x530-52GTXm LEDs are described in Table 13.
D/C 1 - 24
Solid Green The port is operating in full-duplex mode.
Solid Amber The port is operating in half-duplex mode.
Flashing Amber The port is operating in half-duplex mode
with collisions.
Table 12. x530-28GTXm Copper Ports 1 - 24 LED Functions (Continued)
LED Ports State Description
Table 13. x530-52GTXm Copper Ports 1 - 48 LED Functions
LED Ports State Description
L/A
1 - 40
Solid Green The port has established a 1Gbps link to a
network device.
Flashing Green The port is transmitting or receiving data at
1Gbps.
Solid Amber The port has established a 10Mbps or
100Mbps link to a network device.
Flashing Amber The port is transmitting or receiving data at
10Mbps or 100Mbps.
41 - 48
Solid Green The port has established a 1/2.5/5Gbps
link to a network device.
Flashing Green The port is transmitting or receiving data at
1/2.5/5Gbps.
Solid Amber The port has established a 100Mbps link to
a network device.
Flashing Amber The port is transmitting or receiving data at
100Mbps.
Off Possible causes of this state are:
- The port has not established a link with
another network device.
- The LEDs are turned off. To turn on the
LEDs, use the eco-friendly button.
