Anchors for concrete walls
– Two for the x530-28GTXm or x530-28GSX switch
– Four for the x530-10GHXm, x530-18GHXm, x530-28GPXm,
x530-52GTXm or x530-52GPXm switch
Length: 29.6 mm (1.2 in.) Diameter: 6 mm (0.2 in.).
 Screws for wood or concrete walls:
– Two for the x530-28GTXm or x530-28GSX switch
– Four for the x530-10GHXm, x530-18GHXm, x530-28GPXm,
x530-52GTXm or x530-52GPXm switch
Length: 32 mm (1.3 in.) Diameter: 4 mm (0.2 in.)
 Two power cord retaining clips
 Seven rubber feet
Not included with switch:
 Cross-head screwdriver.
 Stud finder for a wooden wall, capable of identifying the middle of
wall studs and hot electrical wiring.
 Drill and 1/4-inch carbide drill bit (for a concrete wall).
Refer to “Installing the Switch on a Concrete Wall” on page 127.
 Plywood base (if you are installing the switch on a wall with
wooden studs). Refer to “Plywood Base for a Wall with Wooden
Studs” on page 120 for illustrations.
 Four screws for attaching the plywood base to the wall.
Caution
The supplied screws and anchors might not be appropriate for all
walls. A qualified building contractor can determine the hardware
requirements for your wall prior to installing the switch.  E88
