2. Printing Measured Values
141
ML-2050A/2051A/2150A
Chapter 6 Printing Set Values and Measured Values
Introduction Part
Installation and
Preparation Part
Operating Part Maintenance Part Appendixes
2. Printing Measured Values
⇒
If the power supply is OFF, turn ON the MAIN POWER switch and then turn ON
the CONTROL keyswitch.
⇒
To print measured values, set welding schedules and output laser light actually.
At this time, "
" (graphic display of measured waveform) of the POWER
MONITOR screen must be turned ON to display the measured waveform. After
making sure that the measured waveform is displayed, perform the following
operations.
1
Displaying the PRINTOUT MODE Screen
(1) Press the TROUBLE RESET key and the CURSOR key (
s
) simultaneously.
The PRINTOUT MODE screen appears.
2
Executing Printing
(1) Move the cursor to "2: POWER MONITOR."
(2) Press the ENTER key.
The previously output measured values are printed.
⇒
The measured values and output waveform that can be printed are only the
previous laser output data. Measured values under other schedules cannot be
printed in succession by specifying SCHEDULE No.
-PRINTOUT MODE WATER
28˚C
SCH.#00
1:SCHEDULE
2:POWER MONITOR
HV:ON POSI.BLINK:ON POSITION:OFF
To Next Page
