1. Installation Place
35
ML-2050A/2051A/2150A
Chapter 1 Installation
Introduction Part
Installation and
Preparation Part
Operating Part Maintenance Part Appendixes
Chapter 1
●
Installation
This chapter explains the installation place and schedules of the laser welder,
and precautions about cooling capacity and room temperature.
⇒
When installing the laser welder, our engineer will take charge of adjustments.
Accordingly, this Operation Manual does not describe the adjusting method at
a startup. When the laser is transferred to another installation place, it may be
necessary for our engineer to perform inspection and re-adjustments.
1. Installation Place
The space required for installing the laser welder and the environment suitable
for the installation are explained below.
Install this laser welder in a sure place at a level with the ground surface. If the
product is operated in inclined or fallen form, a failure will occur.
⇒
For the power supply side, we earnestly recommend using a leakage breaker
with the rated current of 15 A or more, which is applicable to harmonics and
surges.
⇒
Perform class D grounding work (Ministry of Economy, Trade and Industry
"Technical Standards for Electric Equipment").
Space Required for Installation
In the installation place of this product, a space is required in the surroundings.
Install the product in a place remote from the wall as shown in the gure on the next
page. Also, at least 500 mm of space is required in front, back, right, left and upper
sides to cool the internal parts at maintenance.
Installation and
Preparation Part
To Next Page
