3. Name and Function of Each Section on the Lateral Side and Rear Side
3. Name and Function of Each Section on the Lateral
Side and Rear Side
This section explains each section on the lateral side and rear side.
Function of Each Section on the Lateral Side and Rear Side
(1) Side Covers
For both sides of the Laser. Power supply and cooler are beyond the cover.
(2) Rear Cover
For rear side of the Laser. Power supply and cooler are beyond this cover.
(3) Air Filter
At the intake of air. Prevents the Laser from dust and dirt. Cooling fan is
beyond this lter.
(1) (2) (1)
(3)
Side view
Rear view
Side view
