Specications
173
ML-2050A/2051A/2150A
Specications
Oscillator
ML-2050A ML-2051A ML-2150A
Maximum rated output 15 W 7 W 25 W
Max. output energy
15 J/P
(Pulse width 5ms)
7 J/P
(Pulse width 5ms)
25 J/P
(Pulse width 5ms)
Max. peak power 4 kW 2.5 kW 6 kW
Pulse width
Standard: 0.2 to 10.0 ms (0.1 ms steps)
Fine setting: 0.20 to 5.00 ms (0.02 ms steps)
Pulse repetition rate 1 to 30 pps
Oscillation wavelength 1.064 μm
Positioning guide beam Built-in visible laser (Red)
Output stability *1 ±3%
Power
Supply
Power supply
Single-phase 200 V, 220 V, 240 V AC +10%,-15%,
50/60 Hz
Max. input current
7 A
Max. apparent power 1.4 kVA
Breaker rated current
(to be supplied by
customers)
For the power supply side, we earnestly recommend using
a leakage breaker with the rated current of 15 A or more,
which is applicable to harmonics and surges.
Ground Class D (ground resistance: 100 Ω max.)
Cooler
Heat exchange method Forced air cooling
Heat-exchanging ability 850 W (731 kcal/h)
Control
Panel
Schedule setting
(Up to 32 schedules can
be set by combining)
- Laser output waveform - Power monitor
- Repetition rate - Number of repetitions
- Upper/lower limit alarm (Energy monitor [J])
Monitor
Energy monitor (J)
Average power (W)
Counter
9-digit total (preset) counter
9-digit good (preset) counter
Alarm indication Messages are displayed on liquid crystal display.
Operating
Environment
Ambient temperature 5° to 30°C
Ambient humidity
85%RH or less (non-condensing)
<Note>
For the upper limit of ambient humidity, refer to page 37.
Others
Mass Approx. 70 kg
Dimensions 700 (H) x 310 (W) x 665 (D) mm
Noise level (A) Less than 70 dB
