174
ML-2050A/2051A/2150A
Specications
*1 Under the schedule below:
Model Type Laser Output Energy per Pulse Peak Power
ML-2050A
ML-2150A
5 J minimum 1 kW minimum
ML-2051A 0.5 J minimum 0.4 kW minimum
Minimum bending radius of the optical ber
Core diameter Minimum bending radius
φ 0.2, 0.3, 0.4mm 100mm
φ 0.6mm 150mm
φ 0.8mm 200mm
φ 1.0mm 250mm
Standard Values of Maximum Incident Laser Energy and Power of the
Optical Fiber
The following table shows the standard values of maximum laser energy and power
that can be input into the optical ber. Take care not to exceed these values when
using the optical ber.
For single-delivery or timesharing
  
The value becomes 1/2 at 2-powersharing and 1/3 at 3-powersharing.
Core dia.
Model
ML-2050A ML-2051A ML-2150A
SI φ 0.2mm -
7J, 7W
-
SI φ 0.3mm
15J, 15W
SI φ 0.4, 0.6, 0.8, 1.0mm 25J, 25W
⇒
Use an optical ber of φ 0.4 mm core diameter or larger for ML-2150A.
⇒
Use the SI optical ber. The GI optical ber cannot be used.
