1. Setting Welding Schedules
Switching the Accuracy of the Measured Laser
Energy Value (J) (INITIAL Screen)
In the following, the method of switching the measurement accuracy of the
laser energy value (J) is explained.
Usually, this setting permits switching the measured value of 0.1 J increments
over to 0.01 J increments, so that more minute welding work can be performed.
1
Displaying the INITIAL Screen
(1) Turn OFF the CONTROL keyswitch and then turn ON the MAIN POWER switch
while pressing the MENU key.
⇒
Hold down the MENU key until the SELF-CHECK > screen appears.
The power supply is turned ON and the POWER lamp comes on. Then, the
SELF-CHECK > screen appears.
After completion of the self-check, the INITIAL screen appears.
⇒
Unless the CONTROL keyswitch is OFF, the INITIAL screen is not displayed.
2
Switching the Accuracy of the Measured Value (J)
(1) Move the cursor to "6" of "SW1" and press the ON key.
WATER 28˚C
AUTO-START
SELF-CHECK >
INITIALIZE:OFF WATER 28˚C
NETWORK #00
TEMP CONT 30˚C ALARM L20˚C H40˚C
POSITION AUTO OFF 60min
SW1-12345678 SW2-12345678 SW3-12345678
ON ON ON
OFF
OFF OFF
INITIALIZE:OFF WATER 28˚C
NETWORK #00
TEMP CONT 30˚C ALARM L20˚C H40˚C
POSITION AUTO OFF 60min
SW1-12345678 SW2-12345678 SW3-12345678
ON
ON ON
OFF
OFF OFF
