1. Setting Welding Schedules
61
ML-2050A/2051A/2150A
Chapter 2 Various Settings
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
Setting Laser Light Output Schedules
(SCHEDULE Screen)
This section explains the how to set the SCHEDULE screen. On this screen,
the peak value, output time, and output value of laser light and SCHEDULE
number are set.
⇒
32 types of output schedules can be set and registered with SCHEDULE
numbers of #00 to #31. To perform laser welding, enter the registered
SCHEDULE numbers and laser welding can be performed in the set output
schedules.
⇒
It is convenient if you enter the set output schedules in the Appendix "Output
Schedule Data Entry Table" in advance.
⇒
For the details of setting items, refer to "Welding Schedule Setting Screen" on
page 54.
1
Setting Output Schedules by Fixed Waveform (FIX)
Set the output time and output value of laser light in "FLASH1" (first laser) to
"FLASH3" (third laser) by "FIX." Set the laser light that becomes a xed waveform by
up to 3 divisions.
In the following example, SCHEDULE No.: #00, peak value: 4.0 kW, FLASH1: 1.5
ms/100%, FLASH2: 1.5 ms/25%, FLASH3: 3.0 ms/50%, up slope: 0.5 ms, and down
slope: 1.0 ms are set as output schedules.
(1) Press the MENU key to display the SCHEDULE screen.
(2) Move the cursor to "-SCH.#" and press the ON or OFF key to set the SCHEDULE
number.
(3) Move the cursor to "FORM" and press the ON or OFF key to set "FIX."
(4) Move the cursor to "PEAK" and press the ON or OFF key to set the laser output
peak value.
<Note>
The settable maximum peak value of laser output di󰀨ers depending on the model.
ML-2050A: 4.0 kW / ML-2051A: 2.5 kW / ML-2150A: 6.0 kW
(5) Move the cursor to "FLASH1" to "FLASH3" and press the ON or OFF key to set
the laser output time (ms) and laser output value (%).
⇒
The laser output time is set in the range of 0.0 to 10.0 ms. Regarding the laser
output value, the ratio (%) based on the case where the set laser output peak
value is 100% is set.
-SCH.#00 [FORM:FIX ]
≃
0.0J WATER 28˚C
: OFF PEAK=00.00kW REPEAT= 00pps
k
SLOPE 00.0ms

SHOT =0000
FLASH1 00.0ms 000.0%
FLASH2 00.0ms 000.0%
FLASH3 00.0ms 000.0%
m
SLOPE 00.0ms
HV:OFF POSI.BLINK:OFF POSITION:OFF
