ML-2050A/2051A/2150A
1. Setting Welding Schedules
SW2
SW2-1
SW2-2
SW2-3
SW2-4
SW2-5 · 6
SW2-7
SW2-8
Switches the transfer speed of external communication data type assigned to 1 to 8
of "SW (SWITCH) 2" to ON or OFF.
1: Switches the data bit length. OFF: 8 bits/ON: 7 bits
2: Sets whether a parity bit exists or not. OFF: Parity bit/ON: No parity bit
3: Sets the parity mode. OFF: Even/ON: Odd
4: Sets the stop bit. OFF: 2/ON: 1
5 and 6: Set the communication speed.
The following speeds can be set by combining ON and OFF.
5 6 bps
OFF OFF 9600
OFF ON 19200
ON OFF 38400
ON ON (9600)
7: At ON, the automatic laser power monitor value transmission of external
communication becomes ON by default.
8: Unused.
SW3
SW3-1 to 4
SW3-5
SW3-6 to 8
Switches the functions assigned to 1 to 8 of "SW (SWITCH) 3" to ON/OFF.
1,2, 3, and 4: Unused.
5: At ON, pin No.4 (End output) of the EXT.I/O (1) connector is put in a closed circuit
only once after the completion of the set shots. The end signal is also output
when an error occurs during laser output or the laser stop signal is input.
6, 7, and 8: Unused.
WATER
Displays the cooling water temperature. The temperature is measured after
completion of SELF CHECK.
⇒
When the setting of SW1 to SW3 has been changed, be sure to turn OFF the
power to make the setting eective before use.
