ML-2050A/2051A/2150A
2. Setting the Laser Light Delivery
Operating Branch Shutters on the STATUS Screen
In the following, the method of performing open/close operations for branch
shutters on the STATUS screen.
On the STATUS screen, perform open/close operations for branch shutters to transfer
laser light.
For this laser, the following 5 types of sharing specication are available. The DIP
switches in the main unit are initially set according to the specications provided at
delivery.
Sharing type
DIP switch (SW1) settings
6 7 8
Single OFF OFF OFF
2-powersharing OFF OFF ON
3-powersharing OFF ON OFF
2-timesharing ON OFF OFF
3-timesharing ON OFF ON
Operating Procedure
(1) For "BEAM-1", "BEAM-2", and "BEAM-3", move the cursor to the BEAM
corresponding to the connected optical ber and press the ON key.
"BEAM-1", "BEAM-2", and "BEAM-3" correspond to branch shutters 1, 2, and 3
and input units 1, 2, and 3.
⇒
The displayed screen differs depending on the sharing specification. "BEAM-
1" is displayed at single specication. "BEAM-1" and "BEAM-2" are displayed at
2-poweresharing and 2-timesharing. "BEAM-1", "BEAM-2", and "BEAM-3" are
displayed at 3-powersharing and 3-timesharing.
(2) Press the ENTER key.
The branch shutter set to ON is opened and laser light is ready to be transferred.
The branch shutter set to OFF is not opened, so laser light is intercepted.
-STATUS [PANEL CONTROL]

WATER 28˚C
BEAM-1:ON RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:OFF POSI.BLINK:OFF POSITION:OFF
