ML-2050A/2051A/2150A
1. Setting Welding Schedules
Setting the Protection of Optical Fiber
The optical ber is protected from overll to the optical ber. When the core diameter
to be used is set, the maximum possible incident light to the optical ber is calculated
to limit the lamp input power.
(1) Move the cursor to "φ" and press the ON or OFF key to select a core diameter.
The set value at delivery from the factory is SI: φ 1.0 mm, and the settable range
is φ 0.2 to 1.0 mm.
(2) Press the ENTER key.
⇒
When the internal aperture (option) is installed in the oscillator, set a one-size
larger core diameter.
⇒
If the laser output schedules (PEAK, FLASH ms/%, and REPEAT) are not
matched with the set core diameter, Error No.51 FIBER SETTING ERROR or
Error No.48 FIBER OVERRATE is displayed. Then, change the core diameter
setting. For the laser output schedules for the core diameter, refer the Installation
and Preparation Part, Chapter 2 "Standard Values of Maximum Incident Energy
and Power" on page 44.
<Notes>
- When the end face of the optical ber is stained or dirty, the end face of the ber
may be damaged even if no error is displayed. When the optical fiber is not
used, put the cover on it.
- If the GI ber is used, the end face of the ber may be damaged depending on
the condition (energy density to be received by the end face, etc.) even if no
error is displayed.
- When the end face of the ber is damaged, the lens of the connected input unit
or output unit may be stained. Perform inspection and cleaning. When the
input unit has been dismounted, a ber incidence adjustment is required.
Setting the Output Status Check Screen (POWER MONITOR Screen)
In the following, the method of setting the POWER MONITOR screen is
explained. On this screen, the measured energy value of output laser light is
checked, the energy range to be monitored is set, and the upper limit value of
ashlamp input power is set.
Checking the Measured Energy Value of Laser Light
When laser light is output, the POWER MONITOR screen is automatically displayed
and the measured energy value is displayed. If the registered SCHEDULE number is
entered, the measured energy value of the last output laser light can be checked by
the corresponding SCHEDULE number.
(1) Move the cursor to "SCH.#" and press the ON or OFF key. Then, enter the
SCHEDULE number to be displayed.
-STATUS [RS-485 CONTROL]

WATER 28˚C
BEAM-1:OFF RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:OFF POSI.BLINK:OFF POSITION:OFF
