1. Name and Function of Each Section on the Front Side
25
ML-2050A/2051A/2150A
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
Chapter 2
●
Name and Functions of Each Section
1. Name and Function of Each Section on the Front Side
Front Cover Section
This section explains each section of the front cover of the main unit.
Function of Each Section on the Front Cover
(1) MAIN POWER
Switch
Turns ON and OFF the power supply.
(2) Front Door
This door is opened to perform maintenance including cable
connections.
(3) Front Door
Handle
Used to open the front door. Press the button under the handle and the
handle will pop out. After closing the door, put back the handle into place
and the door will lock.
Chapter 2 Name and Functions of Each Section
Introduction Part
(1)
(2)
(3)
