1. Setting Welding Schedules
75
ML-2050A/2051A/2150A
Chapter 2 Various Settings
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
<Note>
When the accuracy of the measured value is switched, the set values of
SCHEDULE are initialized. To prevent misoperation, the setting cannot be changed
unless No.8 of SW1 is set to ON. When the setting of No.6 of SW1 is changed and
the ENTER key is pressed, the setting of No.8 of SW1 is returned to OFF. It takes
about 15 seconds until initialization is completed. The POWER lamp blinks during
that time. Turn o󰀨 the power supply after blinking stops.
3
Setting the Setting Denitively
(1) Press the ENTER key to denitively perform the setting.
The accuracy of the measured value on the POWER MONITOR screen is
switched.
Setting example before switching (SW1-6 OFF)
Setting example after switching (SW1-6 ON)
<Note>
When No.6 of SW1 is set to ON, the settable maximum peak value of laser output
"PEAK" on the SCHEDULE screen becomes 1.0 kW regardless of the model.
-POWER MONITOR SCH.#02 :OFF WATER 28˚C
ENERGY
12.5J
HIGH 045.0J
LOW 000.0J
AVERAGE
12.5W
LAMP INPUT PWR 050%
SHOT
COUNT 123456789 REFERENCE SET 070%
GOOD
COUNT 123456789
HV:OFF POSI.BLINK:OFF POSITION:OFF
-POWER MONITOR SCH.#02 :OFF WATER 28˚C
ENERGY
0.00J
HIGH 45.00J
LOW 00.00J
AVERAGE
0.00W
LAMP INPUT PWR 000%
SHOT
COUNT 123456789 REFERENCE SET 100%
GOOD
COUNT 123456789
HV:OFF POSI.BLINK:OFF POSITION:OFF
