1. Setting Welding Schedules
73
ML-2050A/2051A/2150A
Chapter 2 Various Settings
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
The items that can be protected are as follows.
Display Screen Item
SCHEDULE
Screen
SCH.# (Schedule number)
FORM (FIX/FLEX waveform switching)
PEAK (Laser output peak value)
REPEAT (Number of laser light outputs per second)
SHOT (Total number of laser light outputs)
k
SLOPE (Time for up-sloping to FLASH1)
FLASH1 (Output time ms and output value % of the rst laser)
FLASH2 (Output time ms and output value % of the second laser)
FLASH3 (Output time ms and output value % of the third laser)
m
SLOPE (Time for down-sloping to the last FLASH)
Point1 to 20 (Output time ms and output value % of each point for FLEX)
STATUS Screen RESET SELECT
"
SHOT (Resetting the total number of laser light outputs, SHOT COUNT)
"
GOOD (Resetting the appropriate number of laser light outputs, GOOD
COUNT)
PRESET
"
SHOT (Count-notication setting of the total number of laser light outputs,
SHOT COUNT)
"
GOOD (Count-notication setting of the appropriate number of laser light
outputs, GOOD COUNT)
FIBER (Setting the SI/GI and core diameter)
POWER
MONITOR Screen
SCH.# (Schedule number)
(Graphic waveform display)
HIGH (Upper limit value of laser energy to be monitored)
LOW (Lower limit value of laser energy to be monitored)
REFERENCE SET (Upper limit value of lamp input power)
Common to each
screen
POSI.BLINK (Guide light blinking or lighting ON/OFF)
(2) Press the ENTER key.
The above setting items become unchangeable and the set values are protected.
⇒
To change any set value, enter the password to display the password setting
screen and turn ON "CHANGE VALUE."
