2. Name and Function of Each Section on the Top Side
31
ML-2050A/2051A/2150A
Introduction Part
Installation and Preparation Part
Operating Part Maintenance Part Appendixes
(8) Timesharing
Unit (Only for
timesharing
version)
Mirror to reflect the laser light. This optical-path-switching mirror
directs the laser light to the selected optical ber.
(9) Branch Shutter
(Up to 3 optional
deliveries)
When closed, the laser light is blocked not to output. Depending on
the specication, 1 to 3 branch shutters are installed.
(10) Beamsplitter
(Up to 3 optional
deliveries)
Splits a laser beam into the number of deliveries and reflects them
onto each laser beam input unit. Depending on the specication, 1 to
3 beamsplitters are installed.
Chapter 2 Name and Functions of Each Section
