1. Name and Function of Each Section on the Front Side
27
ML-2050A/2051A/2150A
Introduction Part
Installation and
Preparation Part
Operating Part Maintenance Part Appendixes
(7) RS-485 (2)
Connector
This connector is used to connect the laser to a personal computer
or printer.
(8) REMOTE
INTERLOCK
Connector
Connect it to the Remote Interlock for emergency stop. When
disconnected, the resonator shutter and the branch shutters close
to block the laser beam.
(9) PANEL CONTROL
Connector
At delivery from the factory, the PANEL CONTROL connector and
the LASER CONTROLLER connector are connected by short
circuit cable. For using the optional laser controller, pull out the
short circuit cable.
(10) LASER
CONTROLLER
Connector
This connector is used to connect the optional laser controller. Pull
out the short circuit cable and connect the laser controller. Then,
the laser can be operated at a remote place. (The control panel of
the main unit is not operable.)
(11) Short-Circuiting
Cable
Connected to the [PANEL CONTROL] Connector and [LASER
CONTROLLER] Connector when shipping.
(12) Cooling Water
Tank
Holds cooling water used for cooling the YAG rod, ashlamp and its
power supply.
(13) Water Level Label
Shows proper level of the cooling water.
(14) Ion-Exchanger
Increases purity of the cooling water.
Chapter 2 Name and Functions of Each Section
