ML-2050A/2051A/2150A
1. Setting Welding Schedules
-STATUS [PANEL CONTROL]

WATER 28˚C
BEAM-1:OFF RESET SELECT PRESET
BEAM-2:OFF
"
SHOT 123456789 123456789
BEAM-3:OFF
"
GOOD 123 45 678 9 123 45 678 9
FIBER:[SI] ø1.0mm
HV:OFF POSI.BLINK:OFF POSITION:OFF
POSI.
BLINK
Sets the guide light blinking status (POSITION BLINK) or continuous lighting to ON
or OFF.
When POSI.BLINK is set to ON with the guide light ON, the guide light blinks. If it is
set to OFF, the guide light is put to a continuous ON status.
POSITION
Sets the guide light output to ON or OFF.
When the guide light output is set to ON, guide light is output. When the guide light
output is set to OFF, no guide light is output.
The time until the guide light goes out automatically can be set by "POSITION
AUTO OFF" on the INITIAL screen.
WATER
Displays the cooling water temperature. The temperature is measured after SELF
CHECK is completed.
STATUS Screen
On the STATUS screen, the laser control method is checked and it is set that the
branch shutter to output laser light is opened. In addition, the total number of laser
light outputs and the appropriate number of outputs are set.
How to see the displayed items
: Settable item
-STATUS
Displays the used laser control method.
EXTERNAL CONTROL (external control):
Control is exerted by the PLC connected to the EXT.I/O connector.
PANEL CONTROL (internal control):
Control is exerted by control panel.
RS-485 CONTROL (external communication control):
Control is exerted by the personal computer connected to the RS-485 (1) or
RS-485 (2) connector.
BEAM-1
BEAM-2
BEAM-3
Sets the opening/closing status of branch shutters 1 to 3 to ON or OFF.
When the opening/closing status is set to ON, the branch shutter is opened.
RESET
SELECT
"
SHOT
"
GOOD
Resets the displayed total number of laser light outputs (SHOT COUNT).
Sets the displayed appropriate number of laser light outputs (GOOD COUNT).
PRESET
"
SHOT
"
GOOD
Sets the count-notication function.
When the total number of laser light outputs (SHOT COUNT) and the appropriate
number of laser light outputs (GOOD COUNT) reaches the set number, a message
is displayed.
FIBER
SI
ø
Selects SI (Step Index) or GI (Graded Index) for the optical ber mode to be used.
Usually, SI is used.
To protect the optical ber from overll, set the core diameter of the optical ber to be
used in the range of φ0.2 to 1.0 mm. The maximum value of incidence to the optical
ber is calculated from the set core diameter and the lamp input power is limited.
