Analytik Jena multi EA 4000 User Manual

Operation
multi EA 4000 Version 01.16 73
Connect the reactor and sampler FPG 48
1. Place the ceramic cannula (1) onto the port
with the screw thread.
2. Clamp the pump hose into the cartridge of
the hose pump (2).
The hose end with the connection to the re-
actor must point towards the reactor.
3. Secure the ceramic cannula with the red
screw cap.
4. Check that the sealing cone, seals and
screw cap are fitted on the pump hose.
5. Screw the pump hose finger-tight to the red
screw cap.
