100
Advanced (ADV) Functions Key (Continued)
The message window indicates bolt-hole pattern number 2 and hole number 2. The axis
displays show the distance to hole number 2.
6. Move the machine until the axis displays indicate zero and drill the hole.
7. Repeat these procedures until you have completed all holes in the linear-hole pattern.
To exit the Recall Linear-Hole Pattern function:
8. Press
