Advanced (ADV) Functions Key (Continued)
NOTE: If you are entering a full bolt-hole pattern, skip this section and go to the
Full Bolt-Hole Pattern section.
Partial Bolt-Hole Pattern
To enter a partial bolt-hole pattern for program number 1 (Range is 0 through 9):
1. Press
ENT
The DRO displays the following in the message window:
FULL
To enter a partial bolt-hole pattern:
2. Press
+
_
The DRO displays the following in the message window:
Partial
3. Press
ENT
The DRO displays the following in the message window and axis display 1:
X CENTER
X .0000
