Last Position Save/Recall – F 10/F 11
F 10 allows you to save the machine’s last position before turning OFF the machine; F 11
allows you to recall the saved position after turning ON the machine.
NOTE: If you have EverTrack
TM
Mode, you can always recall all datum points, even if
you move the table during power-off.
IMPORTANT: Lock all axes of machine movement first.
To select the feature and save the last position:
1. Press
The DRO displays the following in the message window:
Save
pos
2. Turn OFF the DRO power.
To recall the saved position:
1. Turn ON the DRO power.
2. Press to recall the last machine
position.
The DRO displays the following in the message window:
recall
pos
3. Unlock the machine and continue with the job.
NOTE: This feature stores display information only. It does not track table movement
when power is turned OFF.
