Printing Axis Values (With I/O Option Only)
NOTE: Before sending data to the printer, ensure that the DRO is not in the Preset
Mode.
To print axis values to a printer:
1. Press to print the data from axis 1.
2. Press to print the data from axis 2.
3. Press to print the data from axis 3.
4. Press to print the data from axis 4.
5. Press to print the data from all
axes.
Printed Axis Value Format
The DRO prints the axis values in the following format:
Axis value unit of measurement counting mode diameter mode
Examples:
X -123.456 mm ABS D
Y 454.902 in INC
W -235.12.30 dms (dms = degree-min-sec)
