Anilam Wizard 900 - Recalling a Preset Dimension

18
Recalling a Preset Dimension
This feature allows you to recall a preset dimension to the axis display.
Use this feature when making multiple moves of the same dimension.
NOTE: This feature works only in Incremental Mode.
To recall a preset dimension:
1. Press
ABS
INCR
to set the display to
Incremental Mode.
2. Press the desired axis key(s) to select the axes.
3. Enter the incremental dimension.
4. Move the machine to zero.
5. Press the desired axis key twice to recall the dimension.
NOTE: You can recall a dimension after you reset absolute zero or when you have
regained power after a power loss.
To clear a preset dimension while in Incremental Mode:
1. Press the desired axis key(s) to select the axes.
2. Press
