Zero Output Time Select
(With I/O Option Only) – F 25
F 25 allows you to specify the time for which a remote device is turned on when the
selected axis crosses zero. (Default: 100 ms) Zero Output – F 33 must be ON.
To change the setting:
1. Press to select the feature.
The DRO displays the following in the message window:
i00 ms
The DRO displays the last-entered setting in the message window.
The available settings are:
Zero Output Time Settings
30 ms, 100 ms (default), 200 ms, 300 ms,
400 ms, 500 ms, 600 ms, 700 ms, 800 ms,
900 ms, and 1 second
