Anilam Wizard 900 - First-Time User Checklist

5
First-Time User Checklist
Your new DRO has many preset values. Before you proceed, please review the
following list to verify default settings. If you need to change any setting(s), refer to
Parameter Settings – F 20.
Description of Setting Factory Setting Your Setting
900 DRO 900E DRO
1. Mill/Lathe/EDM Operation MILL LATHE EDM
2. Linear Encoder Resolution Axis 1 5 µm
Axis 2 5 µm
Axis 3 5 µm
Axis 4 5 µm
3. Direction of Count Axis 1
+
Axis 2
+
Axis 3
+
Axis 4
+
4. Position Tolerance Indicator Axis 1 Set to Zero
Axis 2 Set to Zero
Axis 3 Set to Zero
Axis 4 Set to Zero
5. Audible Keyboard Tone ON
6. Display Resolution Axis 1 .0002 inches (.005mm)
Axis 2 .0002 inches (.005mm)
Axis 3 .0002 inches (.005mm)
Axis 4 .0002 inches (.005mm)
7. Display Dimming 15 Minutes
8. Radius/Diameter Mode Axis 1 Radius Diameter Radius
Axis 2 Radius Diameter Radius
Axis 3 Radius Diameter Radius
Axis 4 Radius Diameter Radius
