Diagnostics – F 45
F 45 allows you to perform system diagnostic tests on the keyboard, internal EEPROM,
and internal counters. If any of these tests fail, contact your local distributor or ANILAM
Customer Services. You do not need to unplug the linear encoders for these tests.
Display Test
1. Press to display all segments of
the display and message
window.
EEProm Test
2. Press to activate the internal
EEPROM test.
The DRO displays the
results in the axis window:
EEProm nF (no fail).
EEPR. FAIL
Counters Test
3. Press to activate the internal
counters test.
The DRO displays the
results in the axis window:
Count nF (no fail).
CNT FAIL
