100-Point Axis Error Compensation F 80/F 81
(Continued)
Selecting the Compensation Table, Entering an Axis Compensation (Continued)
NOTE: For 1-axis version, the compensation point displays only briefly in axis display,
before compensation value is shown. If you press, the CE key, the compensation point
is shown again.
Key Functions for Compensation Table
SET key: Confirm entry and page forward in the compensation table
MM
INCH
MM/INCH key: Page backward in the compensation table.
INCR
ABS/INCR key: Change to “REFERENCE DISPLAY” mode.
ADV key: Direct selection of compensation points.
Press the ADV key and the two-digit number of the desired
compensation point.
Exit the compensation table.
To Next Page
