Anilam Wizard 900 - Full Bolt-Hole Pattern (450 Only)

86
Advanced (ADV) Functions Key (Continued)
Full Bolt-Hole Pattern (N/A for 900, Lathe Mode)
To access the Full Bolt-Hole Pattern function:
1. Press
ADV
repeatedly to scroll through
the Advanced Functions list.
When the DRO displays the following in the message window:
BOLT HOLE
2. Press
ENT
The DRO displays the following in the message window:
BHP NUMBER
To enter a full bolt-hole pattern for program number 2 (Range is 0 through 9):
3. Press
ENT
The DRO displays the following in the message window:
partial
4. Press
+
_
