Linear Encoder Error Detect OFF/ON – F 40/F 41
Your DRO has advanced Linear Encoder error-checking capability. This feature
determines if there are any Linear Encoder miscounts or repeatability problems.
F 40 allows you to turn OFF Linear Encoder Error Detect; F 41 allows you to turn
ON Linear Encoder Error Detect. (Default: ON)
To turn OFF the Linear Encoder Error Detect feature and deactivate all axes:
1. Press
The DRO momentarily displays the following in the message window:
Encerr
off
To turn ON Linear Encoder Error Detect and activate all axes:
1. Press
The DRO momentarily displays the following in the message window:
Encerr
on
If the DRO detects an error, it displays the error in that axis display. The other axis
displays remain blank for a short time and then the beeper sounds.
For example:
X error
