Anilam Wizard 900 - Linear-Hole;Frame-Hole Pattern Function (450 Only)

93
Advanced (ADV) Functions Key (Continued)
Linear-Hole/Frame-Hole Pattern Function (N/A for 900, Lathe Mode)
The Linear Hole pattern function allows you to program a combination of 10 different
linear-hole patterns or frame-hole patterns. Each pattern can include a maximum of 999
holes.
To access the Linear-Hole function:
1. Press
ADV
repeatedly to scroll through
the Advanced Functions list.
When the DRO displays the following in the message window:
LIN HOLE
2. Press
ENT
The DRO displays the following in the message window:
Lhp
NUMBER
X
Y
Figure 4: Linear-Hole Pattern
