Advanced (ADV) Functions Key (Continued)
The message window indicates bolt-hole pattern number 2 and hole number 2. The axis
displays show the distance to hole number 2.
6. Move the machine until the axis displays indicate zero and drill the hole.
To recall the distance to hole number 3:
7. Press
The DRO displays the following in the axis displays and the message window:
2 HOLE 003
X +
.3228
- .2056
After you drill the last hole in the pattern the DRO returns to hole 1 and displays the
following in the message window:
BHP--end
The DRO displays the incremental distance from the absolute zero position in the axis
displays.
To exit the Recall function:
8. Press
