Advanced (ADV) Functions Key (Continued)
To enter the X dimension for the center of the pattern – for example, 1.00 in. (25.4 mm):
4. Press
ENT
The DRO displays the following in the message window and axis display 2:
.0000
CENTER
To enter the Y dimension for the center of the pattern – for example, 1.00 in. (25.4 mm):
5. Press
ENT
The DRO displays the following in the message window and axis display 1:
BHP DIA
X .0000
To enter the diameter of the bolt-hole pattern – for example, 1.00 in. (25.4 mm):
6. Press
ENT
