■ eDP External Power IN (Connector: HIROSE Electric DF1BZ-12DP-2.5DS)

111

122

Pin No. Signal

1 External Power IN2

2 GND

3 External Power IN2

4 GND

5 External Power IN2

6 GND

7 External Power IN1

8 GND

9 External Power IN1

10 GND

11 External Power IN1

12 GND
