SPECIFICATIONS
11.1 Main specifications
11.1.1 Common specifications
Analog 8 - 10 bit: 0.100 - 340.000 MHz
11 - 12 bit: 0.100 - 330.000 MHz
13 - 14 bit: 0.100 - 280.000 MHz
15 - 16 bit: 0.100 - 240.000 MHz
8 - 10 bit: 0.100 - 340.000 MHz
11 - 12 bit: 0.100 - 330.000 MHz
13 - 14 bit: 0.100 - 280.000 MHz
15 - 16 bit: 0.100 - 240.000 MHz
VG-870B/873
Digital
VM-1824 (with Quad output)
8 - 10 bit: 296.000 - 660.000 MHz
11 - 12 bit: 296.000 - 600.000 MHz
Analog 8 to 10 bit: 0.100 - 250.000 MHz
11 - 12 bit: 0.100 - 250.000 MHz
13 - 14 bit: 0.100 - 250.000 MHz
15 - 16 bit: 0.100 - 240.000 MHz
8 - 10 bit: 0.100 - 340.000 MHz
11 - 12 bit: 0.100 - 330.000 MHz
13 - 14 bit: 0.100 - 280.000 MHz
15 - 16 bit: 0.100 - 240.000 MHz
Dot clock frequencies
VG-871B/874
Digital
VM-1824 (with Quad output)
8 - 10 bit: 296.000 - 660.000 MHz
11 - 12 bit: 296.000 - 600.000 MHz
Horizontal frequency Max. 300 kHz, 8192 dots
Number of vertical scanning lines
Max. 8192 lines *1
Video memory 4096 dots × 4096 dots
Serration pulse (Serration) OFF, 0.5H, 1H or EXOR selectable
Scanning
Progressive (non-interlaced), interlaced, segmented
frame, interlace (sync)
*1 The maximum number of vertical scanning lines is 2046 for the DisplayPort output.
