ASTRO VG-873 - Dp;Edp Unit （VM-1826

464
11.1.9 DP/eDP Unit （VM-1826）
Standard VESA DisplayPort Standard Ver.1.1a
Connector DisplayPort×2
Single Mode
16 - 330MHz
Depends on the setting. (Refer to *1)
Dual Mode
32 - 340MHz
Depends on the setting. (Refer to *1)
DotCLK
Split Mode
340 - 660MHz
Depends on the setting. (Refer to *1)
Output color numbers
8/10bit (RGB/ YCbCr444 format)
12bit (YCbCr422)
Audio
Output
L-PCM
Sampling : 32k/ 44.1k/ 48k/ 88.2k/ 96k/176.4/192KHz
Output frequency: from 100 (1/2 of sampling frequency)Hz
Bit number : 16/20/24bit
Link Rate 1.62Gbps / 2.7Gbps DisplayPort
I/F
Lane count 1 / 2 / 4Lanes
DP1
DP2
AUX CH support DPCD, EDID, DDC/CI, HDCP
Connector DX10G1M-50SE (maker : Hirose Electric)
Control signal 8 lines
Power out
4 lines
Internal power（5V/3.3V）/ External power input 1/2
Control
signal
Power out
Power control
signal
RS-232C
eDP
External
power input
Connector DF1BZ-12DP-2.5DS (maker : Hirose Electric)
Input format S/PDIF format
Audio Audio input Coaxial
Sampling frequency Fs = 32 to 96kHz
