6.8.2 Checkerboard pattern customizing
The types of checkerboard patterns are selected and their intervals are set using the procedure below.
(1)
Select Program Edit using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select Pattern (PAT) using
or
INC
DEC
, and then press
SET
.
(3)
Select Pattern/RGB/INV select using
or
INC
DEC
, and then press
SET
.
(4)
Select Checker using
or
INC
DEC
,
and then press
SET
.
(5)
Press
ESC
.
(6)
Select Checker using
or
INC
DEC
,
and then press
SET
.
<Selecting the items>
Select Type using or
INC
DEC
, and
then press
SET
.
(7)
<Setting the parameters>
Select the parameters using
or
INC
DEC
, and then press
SET
.
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For details on the Type settings, refer to “6.8.1 Types of
checkerboard patterns.”
Depending on the Type setting, the setting items differ.
Refer to the <Table of checkerboard setting items>.
