ASTRO VG-873 - Dot Patterns

Chapter 6 PATTERN SETTINGS
341
6.10.4 Dot patterns
The dot pattern settings are described below.
(1)
Select Program Edit using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select Pattern (PAT) using
or
INC
DEC
, and then press
SET
.
(3)
Select Pattern/RGB/INV select using
or
INC
DEC
, and then press
SET
.
(4)
Select Dot using
or
INC
DEC
, and
then press
SET
.
(5)
Press
ESC
.
(6)
Select  × [ABC] using
or
INC
DEC
, and then press
SET
.
(7)
Select Dot using
or
INC
DEC
, and
then press
SET
.
<Setting the items>
Select the items using or
INC
DEC
,
and then press
SET
.
(8)
<Setting the parameters>
Select the parameters using or
INC
DEC
, and then press
SET
.
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For further details, refer to <Table of dot setting items>
below.
