ASTRO VG-873 - Displayport Setting Procedure

Chapter 4 INTERFACE SETTINGS
185
4.12.2 DisplayPort setting procedure
(1)
Select Program Edit using
MENU
or
INC
DEC
, and then press
SET
.
(2)
Select Output (TIM) using
or
INC
DEC
, and then press
SET
.
(3)
Select Digital Output using
or
INC
DEC
, and then press
SET
.
(4)
Select DP using
or
INC
DEC
, and
then press
SET
.
Select the items using or
INC
DEC
,
and then press
SET
.
(5)
<Inputting the parameters>
Select the parameters using or
INC
DEC
, and then press
SET
Alternatively:
Select the parameters using the number keys
(
0/STATUS
to
9/F
), and then press
SET
.
For further details on the parameters, refer to <DP unit
setting parameters>.
