ASTRO VG-873 - Displays Appearing on the VG-871 B; 874 Fluorescent Display Tube

28
2.6 Displays appearing on the VG-871B / 874 fluorescent
display tube
The following information appears on the VG-871B/874 fluorescent display tube.
When selecting and executing programs
Standard display
Group execution
When selecting groups
When adjusting the digital video levels
SAMPLE, TIM and PAT key statuses
ON: S T P OFF: +
Pro
g
ram numbe
r
Name of program or pattern (max. 16 characters)
(
With TIM at OFF
)
Pattern drawin
g
bit len
g
th, horizontal s
y
nc frequenc
y
, vertical s
y
nc frequenc
y
HDCP ON/OFF ON: ⇔z flashing
OFF: z no flashin
g
Group numbe
r
Number of pro
g
ram in
g
roup
Pro
g
ram name
(
max. 16 characters
)
Group numbe
r
Group name
Di
g
ital video level
