ASTRO VG-873 - V-By-One HS Unit

Chapter 11 SPECIFICATIONS
467
11.1.11 V-by-One HS unit
20 to 75 MHz (1 Lane )
40 to 150 MHz (2 Lane )
Normal MODE 8-10 bit
80 to 300 MHz (4 Lane )
160 to 600 MHz (8 Lane )
DotCLK
4k2k (60Hz) MODE
x4 MODE
8-10 bit
320 to 1200MHz (16 Lane)
Video format RGB, YCbCr4:4:4
Color resolution With 8 bits: 256 × RGB (YC) colors
With 10 bits: 1024 × RGB (YC) colors
V-by-One HS1
V-by-One HS2
Level setting With 8 bits: 256 steps
With 10 bits: 1024 steps
●VM-1825画面分割に対する設定単位
HVHV
Mode 0 2dot 2line 4dot 2line
Mode 1 4dot 1line 8dot 1line
Mode 2 2dot 2line 4dot 2line
Mode 3 4dot 1line 8dot 1line
HV
Mode 0 4dot 1line
Mode 1 4dot 1line
Mode 2 4dot 1line
Mode 3 4dot 1line
Mode 4 4dot 1line
8Lane 16Lane
8Lane (x4Mode)
 Setting increments for VM-1825 screen splitting
